ALTO - TMX120DFX
Ce produit n'est plus disponible à la vente
Ces modèles en stock pourraient vous intéresser :
Console de Mixage Amplifiée
Mixeur Amplifié 12 canaux 2x500W RMS sous 4 Ohms et 1000W sous 8 Ohms en mode bridge ALTO TMX120DFX, Effets Intégrés, Alim +48v... Un concentré de qualités qui fait le succès de toute la série EMPIRE d'ALTO.
ARTICLE N° 32381
Caractéristiques
-
ALTO TMX120DFX
-
Série EMPIRE
-
Console Amplifiée 12 canaux
-
Puissance : 2x500W RMS sous 4 Ohms et 1000W sous 8 Ohms en mode bridge, 1400W crête
-
22 entrées.
-
8 entrées micros XLR.
-
12 entrées lignes Jack.
-
1 entrée ligne stéréo RCA.
-
Alimentation fantôme 48V.
-
Processeur d'effets 24 bits intégré.
-
EQ 3 bandes dont médium semi-paramétrique sur chaque canal.
-
Dimensions : 565mm x 450mm x 145mm
-
Poids : 10.6 kg
-
Canaux d'entrées
-
Entrée microphone : symétrique
-
Réponse en fréquence : 20 Hz à 22 kHz, +/-1 dB
-
Distortion : (THDetN) < 0.03% At 0 dBu, 1 kHz
-
Gain range : 0 dB to 40 dB (Mic)
-
SNR (Signal-to-Noise Ratio): 115 dB
-
Entrées lignes : Symétrique
-
Réponse en fréquences : 20 Hz to 22 kHz, +/-1 dB
-
Distortion : (THDetN) < 0.03% at 0 dBu, 1 kHz
-
Gain range : -15 dBu à 30 dBu
-
Impedance d'entrée microphone : 1.4 kOhms
-
Canal d'insert retour : 2.5 kOhms
-
autres entrées : 10 kOhms or Greater
-
Tape Out : 1 kOhms
-
Toutes autres sorties : 120 Ohms
-
Egalisation
-
Hi Shelving : ±15 dB @ 12 kHz
-
Mid bell : ±12 dB @ 100 Hz - 8 kHz
-
Low shelving : ±15 dB @ 80 Hz
-
MAIN EQ 9 EQ : (63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz, 8 kHz, 16 kHz) ±15 dB
-
DSP Section : A/D and D/A Converters 24-bit
-
DSP Resolution : 24-bit
-
Type of effects : Large Hall, Medium Hall, Large Room, Medium Room, Karaoke, Short Spring Reverb, Long Spring Reverb, Chamber, Mono Delay, Mono Echo, Stereo Echo, Flanger, Chorus, Reverb + Chorus, Reverb + Delay, Thickener
-
Presets : 16
-
Controls : 16-Posistion Preset Selector
-
Clip LED
-
Mute switch with peak LED indicator
-
Main Mix Section Noise (Bus noise)
-
Fader 0 dB, Channels muted: 90 dBr (ref.: +4 dBu)
-
Fader 0 dB, All input channels assigned and set to Unity Gain : 88 dBr (ref.: +4 dBu)
-
Power Consumption Stereo mode
-
2 x 500 W @ 4 Ohm (EIAJ) 2 x 340 W @ 4 Ohm (RMS)
-
Bridge mode
-
1000 W @ 8 Ohm (EIAJ)
-
Phantom Power (Mic Pin 2 / Pin 3 and Pin 1) : 47 ±2 V
Présentation
Les performances live sont bien plus qu'un simple "job" ! Elles sont une expérience pour les musiciens, le public ET l'ingénieur du son ! La série EMPIRE TMX a été spécialement conçue pour répondre à toutes vos attentes en terme de performances et faire en sorte que cette expérience reste inoubliable.
Le mixeur amplifié Alto TMX120FX embarque tout ce dont vous avez besoin avec ses 22 entrées (dont 8 XLR/Jack avec alimentations fantômes), 12 jacks ligne et RCA stéréo.. Chaque canal mono et stéréo comprend son propre égaliseur 3 bandes. La conversion A/D et D/A est assurée par une précision 24-Bit.
Pour vous aider dans votre tâche, le processeur d'effets Alesis 24-bit embarqué met à votre disposition 100 presets modifiables afin de colorer votre mix : Echo, Echo+Verb, Tremolo, Plate, Chorus, Vocal, Rotary, Small Room, Flange Verb, Large Hall
Le mixeur amplifié Alto TMX120FX embarque tout ce dont vous avez besoin avec ses 22 entrées (dont 8 XLR/Jack avec alimentations fantômes), 12 jacks ligne et RCA stéréo.. Chaque canal mono et stéréo comprend son propre égaliseur 3 bandes. La conversion A/D et D/A est assurée par une précision 24-Bit.
Pour vous aider dans votre tâche, le processeur d'effets Alesis 24-bit embarqué met à votre disposition 100 presets modifiables afin de colorer votre mix : Echo, Echo+Verb, Tremolo, Plate, Chorus, Vocal, Rotary, Small Room, Flange Verb, Large Hall
Pour aller plus loin...
CREATE AN EXPERIENCE
Live performances are more than just a job, they are an experience for the performers, the audience and for the sound engineer. The EMPIRE TMX series was engineered to precise specifications to deliver the kind of performance you demand, while giving you everything you need to create an unforgettable experience. The EMPIRE TMX120DFX is part of the TMX line, which also includes the TMX200DFX, TMX160DFX and TMX80FX.
PROFESSIONAL CONNECTIVITY
The TMX120DFX is loaded with all the connections you need including 22 total inputs comprised of 8 XLR jacks with phantom power, 12 Line jacks and stereo RCA. These low-noise channels are your best friend when connecting instruments, mics, or even your iPod for playing between sets. Even better, each mono and stereo channel has its own 3-shelf EQ, so you can dial in every nuance you need in seconds. A/D and D/A conversion is performed with 24-bit precision, which means you'll never have a "What was that?" moment. Easy-to-view knobs with incredibly smooth movement help to make mixing feel like playing a fine instrument.
SO MANY EFFECTS, SO LITTLE TIME
The TMX120DFX's on-board Alesis digital effects processor provides pristine 24-bit, ultra-clean digital effects you, and the audience, won't soon forget. Effects include Large Hall, Medium Hall, Large Room, Medium Room, Karaoke, Short Spring Reverb, Long Spring Reverb, Chamber, Mono Delay, Mono Echo,Stereo Echo, Flanger, Chorus, Reverb + Chorus, Reverb + Delay and Thickener.
POWER TO SPARE
Did we mention power? The TMX120DFX comes standard with the ability to deliver ultra-clean power at 2 x 500 W (4-Ohms) or 1000 W (8-Ohms bridged). These aren't peak rating either, this is pure continuous power. In short, it's a workhorse. Fortunately, all that power isn't as heavy as you might expect. Weighing in at just under 24 pounds, the TMX120DFX is a clear winner in the power-to-weight class.
Whether you need just 8 channels, a full 20 or anything in-between, the Alto Professional EMPIRE TMX series has something to help you create an unforgettable experience every time.
Live performances are more than just a job, they are an experience for the performers, the audience and for the sound engineer. The EMPIRE TMX series was engineered to precise specifications to deliver the kind of performance you demand, while giving you everything you need to create an unforgettable experience. The EMPIRE TMX120DFX is part of the TMX line, which also includes the TMX200DFX, TMX160DFX and TMX80FX.
PROFESSIONAL CONNECTIVITY
The TMX120DFX is loaded with all the connections you need including 22 total inputs comprised of 8 XLR jacks with phantom power, 12 Line jacks and stereo RCA. These low-noise channels are your best friend when connecting instruments, mics, or even your iPod for playing between sets. Even better, each mono and stereo channel has its own 3-shelf EQ, so you can dial in every nuance you need in seconds. A/D and D/A conversion is performed with 24-bit precision, which means you'll never have a "What was that?" moment. Easy-to-view knobs with incredibly smooth movement help to make mixing feel like playing a fine instrument.
SO MANY EFFECTS, SO LITTLE TIME
The TMX120DFX's on-board Alesis digital effects processor provides pristine 24-bit, ultra-clean digital effects you, and the audience, won't soon forget. Effects include Large Hall, Medium Hall, Large Room, Medium Room, Karaoke, Short Spring Reverb, Long Spring Reverb, Chamber, Mono Delay, Mono Echo,Stereo Echo, Flanger, Chorus, Reverb + Chorus, Reverb + Delay and Thickener.
POWER TO SPARE
Did we mention power? The TMX120DFX comes standard with the ability to deliver ultra-clean power at 2 x 500 W (4-Ohms) or 1000 W (8-Ohms bridged). These aren't peak rating either, this is pure continuous power. In short, it's a workhorse. Fortunately, all that power isn't as heavy as you might expect. Weighing in at just under 24 pounds, the TMX120DFX is a clear winner in the power-to-weight class.
Whether you need just 8 channels, a full 20 or anything in-between, the Alto Professional EMPIRE TMX series has something to help you create an unforgettable experience every time.
