Horn
The B&C Speakers ME148 is a waveguide optimised for line array applications, offering a wide horizontal coverage of 120° and effective loading from 500 Hz. Designed to exploit the extra octaves of B&C's coaxial compression drivers, it guarantees coherent, controlled diffusion over a wide frequency range.
ARTICLE N° 92175
Presentation
The ME148 has been developed by B&C Speakers to meet the specific requirements of modern line array systems, where control of directivity, vertical coherence and management of connecting frequencies play a central role.
This waveguide adopts an optimised geometry for efficient integration with 1.4" output compression drivers, while maintaining a controlled footprint.
It has been designed to provide a maximum horizontal coverage of 120°, ensuring wide, even distribution, particularly suited to modular configurations or systems requiring extended coverage without multiple sources.
Vertical coverage depends on the configuration chosen, so the system's behaviour can be precisely adjusted according to the number of elements, the coupling angle and the constraints of the location.
A key feature of the ME148 is its highly efficient loading down to 500 Hz. This ability to go low facilitates connection with the midrange or low-midrange channel, while maintaining stable directivity control in an often critical zone.
This feature contributes to a more homogeneous response and a cleaner transition between channels.
This waveguide adopts an optimised geometry for efficient integration with 1.4" output compression drivers, while maintaining a controlled footprint.
It has been designed to provide a maximum horizontal coverage of 120°, ensuring wide, even distribution, particularly suited to modular configurations or systems requiring extended coverage without multiple sources.
Vertical coverage depends on the configuration chosen, so the system's behaviour can be precisely adjusted according to the number of elements, the coupling angle and the constraints of the location.
A key feature of the ME148 is its highly efficient loading down to 500 Hz. This ability to go low facilitates connection with the midrange or low-midrange channel, while maintaining stable directivity control in an often critical zone.
This feature contributes to a more homogeneous response and a cleaner transition between channels.
Other features
-
B&C Speakers ME148
-
Professional waveguide
-
Design type: Optimised line array waveguide
-
Throat diameter: 36 mm (1.4")
-
Crossover frequency: 0.5 kHz
-
Nominal horizontal coverage: 120
-
Vertical coverage: Depends on configuration
-
Acoustic loading: Effective up to 500 Hz
-
Compatibility: Designed for B&C extended octave coaxial compression drivers
-
Material: Polycarbonate
-
Net weight: 750 g
-
Package weight: 1.2 kg
-
Package size: 255 × 255 × 150 mm
-
Packaging: 1 piece
-
ATTENTION: Product sold alone, without compression motor.
