DI Box
Rupert Neve Designs RNDI-S, Active Stereo DI. The history of the RNDI-S is marked by a constant search for sonic perfection. Born from experiments on new types of transformers, the RNDI-S has been refined over time to offer exceptional sound quality.
ARTICLE N° 101170
Presentation
The Rupert Neve Designs RNDI-S is a high-end direct box (DI) that delivers rich, detailed sound.
Using a unique combination of custom transformers and Class A amplifiers, the RNDI-S can:
- Faithfully reproduce the original sound of instruments: Deep, rich bass, clear, precise highs, and detailed sound across the entire sound spectrum.
- Adapt to a wide variety of sources: Whether it's a guitar, keyboard, acoustic instrument, or even a consumer device, the RNDI-S can process and enhance the signal.
- Deliver powerful, dynamic sound: The sound produced is described as "larger than life", meaning it is both powerful and precise.
The result? High-quality direct sound, perfect for studio recording or live performance.
Using a unique combination of custom transformers and Class A amplifiers, the RNDI-S can:
- Faithfully reproduce the original sound of instruments: Deep, rich bass, clear, precise highs, and detailed sound across the entire sound spectrum.
- Adapt to a wide variety of sources: Whether it's a guitar, keyboard, acoustic instrument, or even a consumer device, the RNDI-S can process and enhance the signal.
- Deliver powerful, dynamic sound: The sound produced is described as "larger than life", meaning it is both powerful and precise.
The result? High-quality direct sound, perfect for studio recording or live performance.
Features
Active / passive
Active
Input channels
2
Multichannel
Yes
Power supply
Via +48 V phantom power supply
Packaging
Single unit
Country of production
USA
Other features
-
Rupert Neve Designs RNDI-S
-
Active stereo direct box
-
With Rupert Neve Custom transformer
-
Input headroom: +21.5 dBU
-
Powered via 48 V phantom power
-
Ground switch per channel
-
2x 6.3 mm jack inputs
-
1x 3.5 mm mini-jack
-
2x 6.3 mm jack parallel outputs
-
2x XLR outputs
-
Dimensions: 178 x 127 x 44 mm
-
Weight: 680 g
-
Technical specifications:
-
Noise: Output measurement, unweighted, 22 Hz - 22 kHz, source impedance 150 Ohm. Better than -110 dBV
-
Input impedance:
-
• Instrument input: 2.2 MOhm
-
• 3.5 mm input: 95 KOhm
-
Output impedance:
-
• Less than 40 Ohms
-
Frequency response:
-
• +/ 0.25 dB from 30 Hz to 63 kHz
-
• +/ 1 dB from 12.5 Hz to 120 kHz
-
• 3 dBu at 5 kHz
-
Max input level:
-
• Instrument = +21 dBu (typical)
-
Max output level:
-
• +11.5 dBu output at maximum input level
-
Total harmonic distortion and noise:
-
• @ 1 kHz, input level 20 dBu, no load: 0.009% typical (2nd and 3rd harmonic)
-
• @ 1 kHz, input level +20 dBu, no load: 0.35% typical (2nd and 3rd harmonic)
-
• @ 20 Hz, input level 20 dBu, no load: 0.9% typical (2nd and 3rd harmonic)
-
Crosstalk @ 10 kHz:
-
• Instrument Input: 115 dB
-
• 3.5 mm Input: 108 dB
-
Power Supply;
-
• Phantom Power, 4.5mA @ +48VDC
-
Dimensions: approximately 17.8 cm x 12.7 cm x 4.4 cm
-
Mounting Option:
-
• 19 inch rack shelf, 4-hole pattern (bottom of unit) for 6-32 machine screws
