ELO QUATRO 1600 MK2 Elokance
Active PA Set

Amplified 1600W RMS system Elokance ELO Quatro 1600 MK2, consisting of 4 Elokance ELO 10 MK2 and 2 Elokance ELO SUB15A MK2. Supplied with 4 Speakon 6m PLUGGER cables and 2 coupling bars. The ELO Quatro 1600 MK2 is now equipped with a DSP to optimize the sound of your system according to its use.

ARTICLE N° 59677
  • ELOKANCE ELO QUATRO 1600 MK2
  • Premium package consisting of 4 ELO 10 MK2 and 2 ELO SUB15A MK2
  • Total Power 1600W RMS
  • Built-in DSP
  • Bluetooth Connectivity
  • Granite Paint Finish
  • Protective Grilles
  • Amplifier Class D with integrated DSP.
  • Technical Specifications:
  • Elokance ELO 10 MK2
  • Elo Series
  • Passive Enclosure 10 "" Speaker (25cm)
  • 1 "" (25mm) Compression Coil Power: 200W RMS / 400W Max under 8 Ohms
  • Bandwidth @ -10dB: 65Hz-19Khz
  • SPL Max. : 127 dB
  • Sensitivity (1W / 1m): 97dB
  • Filter cut-off frequency: 2.5 Khz
  • Input connector: 1 x Speakon
  • Output connector: 1 x Speakon
  • 35 mm universal foot connector enclosure
  • Carrying handle on the top
  • Granite paint finish
  • Protective grille on the front
  • Dimensions of the enclosure only: 320 x 280 x 485 mm
  • Weight of the enclosure only: 12 kg
  • ELO Elokance SUB15A MK2
  • Elo Series
  • Active Subwoofer (Amplified)
  • Class D
  • Amplification Built-in DSP with 4 settings: Main, Music, Live, Speech
  • Bluetooth Connectivity
  • 1 High Speaker 15 "(38cm)
  • Power: 500W RMS
  • Amplifier 2 x 150W RMS for satellite outputs
  • Bandwidth @ -10dB: 35Hz-20Khz
  • Limiter and protections against short-circuit and overheating
  • XLR Inputs /Jack 6.35 mm
  • Speakon outputs for
  • satellites Separate level adjustment for Right / Left / Sub.
  • Ground / Lift Selector
  • Mono / Stereo Selector to use the 2 satellite outputs in one channel.
  • Phase selector 0/180 ° for the subwoofer.
  • Universal base 35 mm for speaker stand
  • 2 side carrying handles
  • Finish Epoxy Granite paint
  • Dimensions of the speaker alone: ​​450 x 580 x 486 mm
  • Weight of the speaker only: 38 kg
  • Supplied with 2 speaker stands and 4 cables Speakon 6m PLUGGER
  • Equipped with a very good quality of sound, the Elo series is also very practical because of its scalable capacities: you can add almost as many satellites or subwoofers as you want!
  • Granite Paint Finishing
Application
 Ambiance, Sound reinforcement, Front speaker, Mobile DJ
Line array
 Non
Tweeter
 1"
RMS power (W)
 1600
Integrated mixer
 Yes
Effects
 Audio signal processed by DSP
Streaming
 Bluetooth
Acoustic pressure (dB)
 From 130 to 140
Frequency response
 35 Hz – 19 kHz
Amplification type
 Class D
Connectors
 Jack female Mono, XLR female 3 pins
Outdoor use
 No
Can be used on stand
 Ø 35 mm (1 3/8"), Support d'installation (fourni)
Stands included
 Yes
Case or cover included
 No
Subwoofer included
 Yes
Power supply
 Mains powered
Color
 Black
Speaker
 15", 10"
