Focal - Sub6 Be
The Focal Sub6 Be is an active subwoofer (350W RMS internal amplifier BASH technology) designed for professional monitoring systems. The Focal 27cm composite sandwich diaphragm “W” driver is loaded through a large laminar port. The Sub6 BE can be used as an LFE channel within a multi-channel system. It also offers additional bass or sub-bass in stereo configuration (2.1 or 2.2). The Sub6 was developed to allow optimal acoustic coupling with professional monitoring speakers. For this, it integrates numerous settings such as a stereo high-pass filter (75 Hz – 100 Hz) dedicated to the left and right speakers, a configurable low-pass filter with mono summing, a phase inverter, an adjustable phase, a MUTE switch , a 2.1 bypass controllable using a control pedal (not included), as well as a connector panel rich in possibilities.
Specifications
-
Focal Sub6 Be Active subwoofer.
-
SM6 series.
-
Proximity professional analog control subwoofer.
-
10" 350W RMS active subwoofer.
-
Equipped with a 27 cm (10.6") long excursion subwoofer with “W” composite sandwich membrane.
-
Internal signal processing: Mono right/left summing, LFE + mono low pass, 24 dB / octave, Phase adjustment, Polarity selection, Switchable high pass filter, cutoff frequency selection.
-
Frequency response (+/- 3 dB): 30 Hz - 250 Hz.
-
Maximum SPL level: 116 dB SPL (peak @ 1 m).
-
Connector inputs: 10 kOhm electronically balanced female XLR, variable sensitivity.
-
Outputs to satellite connectors: electronic balanced male XLR 50 Ohm.
-
Low frequency amplifier: 350W RMS, BASH technology.
-
Power supply: Voltages: 230V (1.6 A fuse).
-
Connection: IEC plug and removable power cord.
-
Visualizations and controls:
-
Adjusting the level (sensitivity) of the subwoofer.
-
Setting the cutoff frequency of the low pass filter.
-
Phase adjustment.
-
Polarity reverser.
-
Mute.
-
Bypass 2.1 (controlled by an external pedal).
-
Selection of the cut-off frequency of the high-pass filter.
-
Disabling the high pass filter.
-
19 mm MDF construction with internal reinforcements.
-
Finish: Natural dark red veneer on cheeks, black body.
-
Dimensions (HxWxD): 380 mm x 344 mm x 440 mm.
-
Weight: 23 kg.
-
Package contents: manual, power cord, 1 warranty card, two protective grilles for the Beryllium tweeter (our advice is to remove it for listening as soon as possible) and a plastic bag containing a notice ("Beryllium inverted dome tweeter), as well as an adhesive strip to affix to the tweeter in the event of damage to the dome, 4 rubber pads, 1 Hallen key no. 4.
-
The Sub6 monitor was developed to allow optimal acoustic coupling with Focal monitoring speakers. To do this, it integrates numerous settings such as a stereo high-pass filter (75 Hz – 100 Hz) dedicated to the left and right speakers, a configurable low-pass filter with mono summing, a phase inverter, an adjustable phase or even a switch. MUTE.
-
An important advantage: the Sub6 has a footswitch input. It allows you to connect a pedal and has the effect of muting the subwoofer as well as deactivating the high-pass filters on the outputs supplying the monitors. The footswitch input allows you to compare listening in 2.1 (Sub6 filtered + monitors filtered by Sub6) and in 2.0 (subwoofer deactivated + wideband monitors). The comparison is made instantly, by simply pressing the footswitch, and without the need to move.
Presentation
The richness of the connections allows use in 2.1, 2.2 and multichannel via the L/R inputs and outputs and the LFE input. The numerous settings, such as the high-pass filter dedicated to monitors, the fully adjustable phase and the level management, ensure optimal coupling with the Solo6 Be and Twin6 Be monitors.
Last point, the little extra that makes a big difference: the footswitch input. It allows you to connect a pedal and has the effect of muting the subwoofer and deactivating the high-pass filters on the outputs supplying the monitors. This greatly simplifies and improves the control of the work carried out during the different phases of the musical project.
