B&C Speakers - 12NDL76 8 Ohm Push Buttons

The B&C Speakers 12NDL76 8 Ohm Push Buttons is a speaker designed to deliver precise and energetic sound reproduction in the low-midrange and bass registers, while ensuring excellent efficiency thanks to its neodymium motor.
With a diameter of 12 inches and a 76 mm aluminum voice coil, it stands out for its ability to handle a continuous power of 800 W AES while maintaining a high sensitivity of 100 dB 1W/1m.

This configuration allows it to ensure dynamic and punchy reproduction, particularly in high sound pressure sound systems where responsiveness and precision are essential. Its treated paper cone, coupled with a double roll suspension, guarantees good displacement control and a balanced frequency response between 50 Hz and 2 kHz.

The architecture of the B&C Speakers 12NDL76 is based on an optimal compromise between robustness and lightness, thanks to the use of a neodymium magnet. Its Qts of 0.2 and its resonance frequency of 50 Hz make it a transducer particularly suited to 42-liter bass-reflex loads tuned to 65 Hz, thus optimizing bass reproduction while minimizing distortion.

In addition, its Xmax of 7 mm guarantees sufficient excursion to manage high sound pressure levels, while maintaining its linearity across the entire usable spectrum.

Designed for use in a professional environment, the 12NDL76 8 Ohm Push Buttons benefits from a Push Buttons connector that facilitates wiring and ensures reliable contact. Its simple spider ensures good cone stability while allowing a rapid response to requests, while its exponential cone promotes a homogeneous dispersion of midrange frequencies.
