Tascam - AE-4D
The Tascam AE-4D is a 4-channel AES/EBU ↔ Dante converter in a 1U half-rack format. Compatible with Dante, AES67 and Dante Domain Manager, it supports the transmission of digital signals up to 96 kHz / 24-bit, whilst offering remote control via Tascam DCP Connect and EZ Connect.
Presentation
Designed for professional environments, it is ideally suited to recording studios, audiovisual installations, broadcast control rooms and fixed audio systems. Its compact 1U half-rack format makes it easy to install in a rack, under a table or in an equipment cabinet.
The AE-4D prioritises ease of use with software control of levels and mute functions via Tascam DCP Connect. Its PoE power supply reduces the amount of cabling required and enables quick installation when a compatible switch is available. Compatible with Dante Controller, Dante Domain Manager and AES67, it integrates easily into even the most demanding networked audio infrastructures.
Features
Other features
-
Tascam AE-4D
-
Dante / AES67 audio interface
-
AES/EBU ↔ Dante digital audio converter
-
Form factor: 1U half-rack
-
2 AES/EBU inputs: 3-pin XLR
-
2 AES/EBU outputs: 3-pin XLR
-
4 Dante inputs: RJ45
-
4 Dante outputs: RJ45
-
Resolution: 16 / 24-bit
-
Sampling rates: 44.1 / 48 / 88.2 / 96 kHz
-
Up to 4 channels at 44.1 / 48 kHz
-
Up to 2 channels at 88.2 / 96 kHz
-
Integrated sample rate converter on the AES/EBU inputs
-
Individual level control (faders)
-
Mute function on each input and output
-
2 balanced AES/EBU XLR inputs
-
AES3-2003 / IEC60958-4 (AES/EBU) format
-
AES input impedance: 110 Ω
-
Supported AES input sample rates: 32 to 192 kHz
-
2 balanced AES/EBU XLR outputs
-
Output impedance: 110 Ω
-
AES output sample rates: 44.1 / 48 / 88.2 / 96 kHz
-
2 RJ45 Gigabit Ethernet ports
-
Dante, AES67, Dante daisy-chain
-
1000BASE-T (IEEE 802.3ab)
-
Compatible with Cat5e STP cables or higher
-
Compatible with Dante Controller, Dante Domain Manager, Tascam DCP Connect, EZ Connect
-
Compatible with macOS, Windows, iOS, Android
-
Power supply: Class 0 PoE, PS-P1220E adapter (optional)
-
Power consumption: 3 W
-
AK-RS1 rack-mount kit available as an option
-
Dimensions: 214 × 45 × 136 mm
-
Weight: 795 g
